PCI Expansion Slot | Everything You Need to Know

Share on:

In the world of data transfer and connectivity, expansion slots are the standard for achieving peak performance in an affordable yet easy way. Over the years, expansion slots have seen many upgrades and types depending on user demand. In this article, we’re going to discuss everything you need to know about the PCI expansion slot.

PCI Expansion Slot Fi

Expansion Slot, Expansion Card, and Expansion Bus

Before going into the world of a PCI expansion slot, we first need to know some basic terminologies. Expansion slots are commonly found in computer devices, and it has a counterpart named “expansion card” or board. The expansion slot is a type of connector used as a point where hardware components can be installed. It is generally fitted on the motherboard or riser card. It is a widely used technology that has been used for many years since its inception in 1973.

The expansion card is basically a PCB (Printed circuit board) that goes into the expansion slot. It is found with the external hardware components. Expansion cards are installed into the expansion slot, and they transfer data between them through expansion buses. PCI slots differ for various motherboards, and you can check the motherboard to learn about its slot info, and if needed, upgrade the motherboard itself.

Expansion-Slot,-Expansion-Card,-and-Expansion-Bus

Expansion buses are the bridge through which data transfer occurs between the hardware and the motherboard. A set of low resistance connectors are used for this purpose. The better the bus system is, the higher the bandwidth between devices. To determine the quality of the bus, we measure their clock speed, bandwidth (data transfer rate), and the “width” which is defined as 32-bits and 64-bits in general.

PCI Expansion Slot

An Overview

The PCI expansion slot is one of the most widely used methods of expansion slot. These are convenient slots situated into the motherboard for hardware connectivity. PCI means “Peripheral Component Interconnect”. It can be used to install almost any type of hardware as long as the versions are correct.

Due to the high level of compatibility and data transfer rate, PCI expansion slots have been at the peak. We also have upgraded and more powerful expansion methods like PCIe (PCI Express) and PCI-X (PCI Extended) who are the direct descendants of PCI expansion slots.

PCI expansion slots can be used in many applications such as the sound card, ethernet systems, and network cards, video cards or GPUs, modems, SCSI, RAM, SSD, and many more.

Basic Structure of PCI

PCI expansion slots come in different sizes, but the basic looks are almost the same. It’s a long slot that looks much like a rail line. The slot has a lot of holes with a connector inside, and a long tiny slotted hole in the middle. PCI slots come with notches, that differentiate between the versions of cards it can support.

The connectors of PCI cards are called “Edge connectors” which are used to connect them to the expansion slots after inserted. In typical motherboards, we can see up to 7 expansion slots for different purposes. Another physical type is the daughterboard which is directly mounted to the system. These daughterboards contain attachments like pins and sockets to be inserted into other physical components.

Basic Structure of PCI

The location of the notch changes with different versions, so that incompatible versions can’t be inserted physically into the slot. The number of notches also changes with the voltage and bit-width. Generally, PCI slots come with 3.3V or 5V operating voltage. The 5V cards have notches that are further from the edge, whereas the 3.3V cards have notches closer to the edge of the card. Universal cards possess notches at both locations so that they can be used in both 5V and 3.3V devices. The PCI slots with 64-bit bus widths have one extra notch in their connectors.

How to Use

PCI expansion slots are very easy to use. These slots come pre-loaded into the motherboard. So, it is better to buy a motherboard with more PCI or PCIe slots for further upgrades and more accessibility. To use the PCI slots, we need to choose hardware that comes with compatible versions of PCI expansion cards.

How to Use

If compatible, we can attach the expansion card directly into the expansion slot by pushing them inwards until the grip between them is firm. The contact points must be clean before inserting the component, otherwise, the bandwidth will be affected, and even the connection may hamper. Incompatible PCI cards can’t be used in the same motherboard, so different specialized connectors can be used.

Types of PCI Expansion Slots

Originating from the old PC-XT and PC-AT technologies, which were communized as ISA (Industry Standard Architecture), PCI slots come in different versions and types. There are several PCI versions available to date. They are named PCI 1.0, PCI 2.0, PCI 2.2, and so on. Each of the newer versions carries more bandwidth and clock speed also varies between them. But there are different types of PCI too, which are used for different purposes.

  1. PCI 32-bit slots
  2. PCI 64-bit slots
  3. PCI-X slots
  4. AGP and AGP Pro slots
  5. PCIe or PCI-E slots

PCI 32-bit

These are the most commonly seen PCI slots and cards. 32-bit PCI cards have 1 notch. The notch is located close to the starting point of connectors for 3.3V cards, and at the endpoint for 5V cards. It isn’t forward compatible with the 64-bit variant because of the physical location of notches, and the 32 connector positions on the card.

PCI 32-bit

PCI 64-bit

The common way to identify a 64-bit PCI card is the 2 notches compared to only 1 notch for 32-bit cards, and it’s slightly longer than the 32-bit. In 3.3V 64-bit PCI, the notches are at the 2 ends of the card, whereas 5V 64-bit has 2 notches very close to each other. 64-bit PCI cards have 32 contacts on both sides of the cards for more detailed purposes.

PCI-X

Also known as PCI-Extended, the PCI-X is backward compatible with previous versions of PCI slots. It is a 64-bit width bus that can be used in 32-bit PCI interfaces too. PCI-X slots are most commonly used in servers to fulfill the need for higher bandwidths. PCI-X 1.0 has 133MHz clock speed, and PCI-X 2.0 has 533MHz clock. The delivered data transfer speed is 1064MB/s.

AGP and AGP Pro

AGP (Accelerated Graphics Port) is another type of specialized PCI expansion slot used only for video cards. Before PCIe came in, AGP was the method for using graphics cards. These are smaller in length than the PCI slots and are incompatible to them.

AGP and AGP Pro
AGP and AGP Pro 2
AGP and AGP Pro 3

PCIe or PCI-E

A major upgrade from the previous generation PCI cards is the PCIe (Peripheral Component Interconnect- Express) or PCI-Express cards, which replaced the original PCI models and is used in almost every system today.

PCIe or PCI-E

PCIe is superior to all the PCI versions including PCI-X due to the much higher bandwidth and better compatibility. While PCI was neither forward nor backward compatible, PCIe is compatible across all its versions. However, it isn’t compatible with the PCI.

PCIe utilizes a series transfer method unlike the parallel one of PCI. This prevents bottlenecking when multiple PCIe cards are in use while keeping the bandwidth to its max. Structurally all the PCIe slots are the same, only difference in length. So, any PCIe card can be used in any PCIe slots. Open-ended PCIe slots are also available to fit bigger cards into smaller ports.

PCIe or PCI-E 2

Unlike PCI, PCIe can handle graphics cards too. Mainly PCIe x16 is used for this operation. PCIe comes in x1, x2, x4, x8, x16, and x32 versions which describe how many series of data can pass through the bus. Almost all the modern-day hardware components like graphics cards, RAM, sound cards, ethernets, are compatible in PCIe expansion slots.

Conclusion

In this article, we’ve summarized an overview of the PCI expansion slot, its types, and its applications. The PCI expansion slot is one of the most popular and globally used methods for attaching expansion cards into the system for various types of needs. It is crucial to understand the versions and compatibility ranges of this technology to fully utilize them.
